Advanced Electrical Componentry
Minimize downtown and maintenance requirements with the regenerative braking and brushless AC motor on the WSTX30/35. The infinitely variable travel controller and AC drive motor ensure high torque through the driving range, ensuring optimal performance. Travel speed remains constant relative to the throttle position, regardless of the truck load, providing superior operator ergonomics and easy-of-operation. The EPD emergency power disconnect shuts off all power to the system when activated, and can be reset with a simple twist.
Hydraulics
The self-contained hydraulic power unit is sealed against dust and dirt, extending the life of your truck for years to come. The pressure-compensated valve regulates the lowering speeds, promoting operator safety and smooth descent of the forks.
Brakes
The electromagnetic brakes on the WSTX30/35 reduce the total cost of ownership, by eliminating the need for costly brake jobs. The brakes are mounted to the motor armature shaft, multiplying the braking power through the transmission. The brakes are automatically applied when the control arm is in the fully horizontal or vertical position. Additionally, travel speed is reduced when the truck is in operation and the forks are raised. When the WSTX30/35 comes to rest on an incline, the position hold feature on the electromagnetic brakes prevent rollback.
Transmission
Reduce noise and maintenance cost while improving efficiency and performance with the state-of-the-art optimized gear technology within the transmission of the WSTX30/35. The vertically mounted drive motor is directly mounted to the gear housing, boosting efficiency.
Controls
The ergonomic control handle includes travel, lift, and lower functions, designed for operation with either hand. The lift and lower controls are fully proportional, allowing operators to maneuver with ease. Standard equipment includes a wrap around hand guard, reverse switch, dual butterfly thumb controls, and a horn.
Serviceability
The WSTX30/35 is easy to maintain and even easier to service, with a removable power head cover that exposes the major hydraulic and electrical components. Reduce overall operating costs and maintenance time with the WSTX30-35.
Frame and Mast
The WSTX30/35 is Built to Last, with a heavy duty frame that is compact but durable. The I-beam mast adds stability and strength to the WSTX30/35, with dual lifting chains and integrated lift cylinders in line with the outer I-beam.
